The SF-ODUD 1200W-4000W input voltage is flexible (110V/220V self-adaptive), the inverter output is 220VAC±10% or 110VAC±10%, the frequency is 50/60Hz±1%, and the pure sine wave is compatible with sensitive equipment.
Product features
| Model | SF-OFUD1.2 | SF-OFUD1.6 | SF-OFUD2.4 | SF-OFUD4 | |
| AC Input voltage | 220VAC(standard) | ||||
| Input voltage range | 154-264VAC±3V(Nor Model) 185-264VAC±3V(UPS Model) 110V Model:77-132VAC±3V(Nor Model) 92-132VAC±3V(UPS Model) | ||||
| Input frequency | 50/60Hz±5% | ||||
| Out put power | 1200W | 1600W | 2400W | 4000W | |
| AC model output Voltage | The output voltage under the mains is the same as the input voltage | ||||
| AC model output frequency | The output frequency under the mains is the same as the input freguency | ||||
| Battery model output voltage | 220VAC+10%(customizable 110VAC+10%) | ||||
| Battery model output frequency | 50HZ or 60HZ+1% | ||||
| Battery model output wave | Pure sine wove | ||||
| Battery type | External lead-acid battery,Gel battery,water battery or Lithiun battery | ||||
| Battery voltage | 12VCD | 24VCD | 24VCD | 48VCD | |
| Battery charging voltage | 13.7VDC | 27.4VDC | 27.4VDC | 54.8VDC | |
| Maximum PV array power | 12V:800W 24V:1600W | 48V:6400W | |||
| Solar input voltage range | 12V:MPPT 15V-I0VDC 24V:MPPT 30V-I50VDC 48V:MPPT 60V-I50VDC | ||||
| Maximum PV Display Open Circuit Voltage | 12V:PWM 50VDC 24V:MPPT I50VDC 48V:MPPT I50VDC | ||||
| Maximum solar charging curent | 60A | 120A | |||
| Maximum AC Charge Current | 40A | 33A | 50A | 41A | |
| Transter time | ≤10ms（UPS Mode）/≤20ms（INV Mode) | ||||
| load peak ratio | (MAX)3:1 | ||||
| Protective function | Under the mains:input over current fuse Under inverter: overload protection,short circuit protection,low voltage protection, (with battery anti-reverse connection, board). | ||||
| Status Display | You can view parameters such as AC voltage,ACtrequency,PV voltage,Pv curent output voltage. output frequency, battery voltage, load current and other parameters by turning the page keys. | ||||
| Voice prompt | low battery protection buzzer long beep Blow battery buzzer beeps every second Machine fault burzer beeps Overioad buzzer beeps When the overload is less than 130%, the buzzer will sound every second,and the output wil be turned off after 30s. When the overioad is greater than 150%, the output will be turned off after 300ms. | ||||
| Operating temperature | (-10℃-50℃) | ||||
| Storage temperature | ( -15℃-45℃) | ||||
| Relative temperature | (-10°C-90°C) no condensation | ||||
| Noise | <45dB | ||||
